Automatic Seedling Grading Machine for Commercial Nurseries
The JFT-F1000XB Automatic Seedling Grading Machine is designed for plug-seedling nurseries that need to classify seedlings before transplanting, cultivation or batch handling. The system grades seedlings into three levels based on stem diameter, stem height and leaf information.
For commercial nurseries, grading becomes difficult to scale when thousands of seedlings must be checked tray by tray. JFT-F1000XB transfers this repetitive inspection and classification process into an automated equipment workflow.
What Is an Automatic Seedling Grading Machine?
An automatic seedling grading machine evaluates plug seedlings according to measurable plant characteristics and separates them into defined groups. The JFT-F1000XB uses stem diameter, stem height and leaf information to classify seedlings into three grades before downstream transplanting or nursery handling.
Why Automate Seedling Grading?
Transitioning from manual evaluation to an automated classification workflow creates consistency across commercial nursery batches.
Mixed Seedling Size in the Same Batch
Seedlings from the same production batch may develop at different rates, creating variation in stem diameter, height and leaf growth.
JFT-F1000XB evaluates these characteristics and separates seedlings into three grades.
Nursery operators can send more uniform groups into transplanting, cultivation or order preparation.
Manual Visual Judgement
When workers grade seedlings by eye, results may vary between operators and shifts.
The machine applies the same grading criteria across the batch.
Production managers gain a more repeatable grading workflow without relying entirely on individual judgement.
High Labor Demand Before Transplanting
Large numbers of trays often need grading within a limited time before seedlings move to the next production stage.
The JFT-F1000XB processes approximately 3,000–5,000 seedlings per hour according to the provided product specification.
The grading stage can be planned around a defined machine capacity instead of expanding manual grading tables.
Downstream Production Needs More Uniform Seedlings
Automatic transplanting and standardized cultivation work more smoothly when incoming seedlings are grouped by size and growth condition.
Three-grade classification creates more consistent batches for downstream operations.
Nurseries can organize transplanting, cultivation and handling according to seedling grade.
Applicable Crop Seedlings
How the JFT-F1000XB Seedling Grading Process Works
The machine evaluates seedling stem diameter, stem height and leaf information and assigns the plug seedlings to three grading levels.
JFT-F1000XB Automatic Seedling Grading Machine Operation Video
https://aigraftrobot.com/wp-content/uploads/2026/07/seedling-grading-and-transplanting-machine.mp4Three-Level Grading
Seedlings are classified into three groups according to defined growth information.
Stem Diameter Evaluation
Supports grading based on stem thickness information.
Seedling Height Evaluation
Supports classification based on plant height information.
Leaf Information Evaluation
Leaf characteristics are included in the grading decision according to the machine configuration.
JFT-F1000XB Technical Specifications
Detailed configuration and operational parameters for the automatic nursery grading machine.
What Buyers Should Confirm Before Ordering
Machine configuration should be evaluated against the customer's seedling type, tray format, growth variation and downstream transplanting or cultivation process.
| Model | JFT-F1000XB |
|---|---|
| Product Type | Automatic Seedling Grading Machine |
| Overall Dimensions | 1980 × 1750 × 1820 mm |
| Applicable Seedlings | Fruit and vegetable seedlings, flowers, Chinese medicinal plant seedlings and other compatible nursery crops |
| Grading Accuracy | ≥98% |
| Gripper Quantity | 12, configurable |
| Processing Capacity | 3,000–5,000 seedlings/hour |
| Machine Weight | 900 kg |
| Air Pressure | 0.4–0.6 MPa |
| Rated Power | 2.8 kW |
| Voltage | 220 V |
| Grading Method | Three-grade classification based on stem diameter, stem height and leaf information |
| Other Specs (Temp, Warranty, etc.) | Available upon technical confirmation. |
Suitable Nursery Applications
Seedling Nurseries
In commercial nurseries, the JFT-F1000XB is frequently deployed alongside other equipment to build a comprehensive production line. Prior to grading, trays may be processed by an Automatic Precision Seeder. For grafting workflows, seedlings are prepared using a Seedling Grafting Robot. Missing cells in trays can be fixed with a Seedling Selection & Replenishment Machine. After grading, uniformly sized batches are often fed into an Automatic Seedling Transplanting Machine. All these modules can be combined into a complete Integrated Nursery Automation layout.
Evaluate JFT-F1000XB for Your Nursery
Send seedling photos and tray information so the AiGRAFT team can review whether the grading method and machine configuration match your nursery workflow.
AiGRAFT Nursery Automation Equipment
AiGRAFT develops equipment covering precision seeding, grafting, seedling selection, grading and transplanting.
Integrated Nursery Equipment Options
JFT-F1000XB can be evaluated as a standalone grading machine or as part of a connected nursery automation workflow.
